Brandmotion SummitView Adjustable Rear Vision System for 07-18+ Wrangler JK/JL Aftermarket Display SUTV-8848

SKU
BRM-SUTV-8848
We Price Match
High Quality CMOS Camera
Jeep Wrangler Specific Harness
648 x 488 Resolution 480p
0.1 Lux For Better Illumination And A Sharper Image
Parking Gridlines Standard (Non-removable)
Special Price $228.61 Regular Price $268.95
Brand Motion SUTV-8848

Finally an answer for Jeep Wrangler owners who want to add the safety and practicality of Rear Vision! Brandmotion's exclusive line of Jeep Wrangler Rear Vision Systems gives you the edge in offering high quality back-up protection that's not available anywhere else using our patented Stainless Steel Jeep bracket to guarantee a perfect fit!

This rear vision kit uses the highest quality CMOS camera you can buy, an improved design camera with exceptional image clarity and crispness, as well as enhanced brightness for backing up at night. This kit is designed for Jeep Wranglers with virtually any wheel, including the spare tire. It is compatible with vehicles with an aftermarket display such as an aftermarket navigation radio or another display monitor. This system includes a composite (RCA) connection to the video input monitor. Additionally, this system includes the RCA to Factory 22 Pin connector for customers who wish to get the vehicle programmed by a dealer.

This kit is designed for virtually any wheel, standard parking gridlines and an aftermarket display. For customers who are trying to use this with a factory display, additional parts are needed, or you will need to get it programmed at a dealer. This kit is designed to work with both automatic and manual transmission vehicles.



Fitment:

2007-18 Jeep Wrangler (JK)
2018+ Jeep Wrangler (JL)



Features:

Integration
Brandmotion™ Exclusive Stainless Steel Rear Tire Mount Ensures Perfect Fit
Better Than OEM Design Allows For Seamless Integration
Fully Adjustable Camera Bracket Design To Accommodate Virtually Any Wheel
Includes Factory 22 Pin to RCA Connector

Camera Specifications:
High Quality CMOS Camera
Jeep Wrangler Specific Harness
648 x 488 Resolution 480p
0.1 Lux For Better Illumination And A Sharper Image
Parking Gridlines Standard (Non-removable)
Format: NTSC
9-16V Operating Voltage Range
Color Image With Automatic White Balance
Electric Auto Iris
150º Horizontal Field of View
100º Vertical Field of View
Waterproof Case With Anti-fog Lens
IP Rating: IP 68



Notes:

*Note: For customers looking for an enhanced driving experience, please see FVMR-8886.

**Note: For customers looking to retain their third brake light with oversized tires on their Jeep Wrangler JK, please see SUTV-8894.

***Note: If you have ordered this kit in error with the intention of installing this on the factory screen, you can convert this to work with the factory display by adding the 9002-6115V2.

****Note: If you are looking for a replacement for just the camera, you can purchase 9002-7601 and simply remove it from the license plate bracket. You are required to change both the camera and the harness for everything to function properly and the warranty honored.

If you are looking for a single camera rear vision system for a factory display radio, please see SUTV-8847.

If you are looking for a dual camera vision system for a factory display radio, please see SUTV-8849.

More Information
ManufacturerBrand Motion
Searchable SkuSUTV-8848
